TP-Link EAP623-Outdoor HD

Popis produktu:

TP-Link EAP650-Outdoor
AX1800 Indoor/Outdoor Wi-Fi 6 Access Point

Až 1,8 Gbps WiFi 6 rychlostí: 574 Mbps na 2,4 GHz + 1201 Mbps na 5 GHz
Podporuje technologie WiFi 6 1024-QAM a OFDMA atd
Konektivita s vysokou hustotou až 1 000+ klientů
Dlouhý dosah pokrytí s vysoce výkonným zesilovačem a chytrými anténami.
Krytí IP67 odolné proti povětrnostním vlivům pro různá venkovní prostředí.
Pokročilé funkce: Centralizovaná správa, síť Omada a bezproblémový roaming.
Napájení PoE+: Podporuje 802.3at PoE (adaptér není součástí dodávky)

Stránky produktu: https://www.tp-link.com/cz/business-networking/omada-wifi-outdoor/eap623-outdoor-hd/
Technické specifikace


HARDWARE FEATURES
Interface 1x Gigabit Ethernet Port
Button Reset
Power Supply • 802.3at PoE

• 48V Passive PoE

Note: PoE adapter is not included.
Dimensions ( W x D x H ) 11.0 x 4.2 x 2.2 in (280.4 × 106.5 × 56.8 mm)
Antenna Type 2× Internal Dual-Band Omni Antennas

• 2.4 GHz: 4.0 dBi;

• 5 GHz: 5.0 dBi
Weatherproof Enclosure IP67
Mounting Pole/Wall Mounting (Kits included)


WIRELESS FEATURES
Concurrent Clients 1,020+**
Wireless Standards IEEE 802.11 a/b/g/n/ac/ax
Frequency 5 GHz, and 2.4 GHz
Signal Rate • 5 GHz: Up to 1201 Mbps

• 2.4 GHz: Up to 574 Mbps
Wireless Functions • Mesh?

• Seamless Roaming?

• Automatic Channel Assignment

• Load Balance

• Band Steering

• Beamforming

• Airtime Fairness

• Multiple SSIDs:16 (8 for each band)

• Wireless Statistics

• Wireless Schedule

• Reboot Schedule

• RADIUS Accounting

• MAC Authentication

• Static IP/Dynamic IP
Wireless Security • VLAN

• Access Control

• Rogue AP Detection

• Captive Portal Authentication?

• Maximum number of MAC Filter: 4,000

• Wireless Isolation between Clients

• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

• 802.1X Support
Transmission Power • CE:
MANAGEMENT
Omada App Yes
Restore & Backup Yes
Firmware update via Web Yes
NTP Yes
Centralized Management • Omada Hardware Controller (OC300)

• Omada Hardware Controller (OC200)

• Omada Software Controller

• Omada Cloud-Based Controller
Cloud Access Yes. Require the use of OC300, OC200, the Omada Software Controller, or Omada Cloud-Based Controller.
Email Alerts Yes
LED ON/OFF Control Yes
Management MAC Access Control Yes
SNMP v1, v2c, v3
SSH Yes
Web-based Management Yes


OTHERS
Certification CE, FCC, RoHS
Package Contents • EAP623-Outdoor HD

• Installation Guide

• Mounting Kit

• Waterproof Kit
Environment • Operating Temperature: -30 °C–70 °C (-22 °F–158 °F);

• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);

• Operating Humidity: 10%–90% non-condensing;

• Storage Humidity: 5%–90% non-condensing

Specifikace:
